Shipping info: These are FULLY CONSTRUCTED so the $87 shipping cost list is WA & Vic areas only as this is where our supply warehouses are located! If you are in any other location there will be an additional shipping cost, Please order now & we will contact you BEFORE processing the order with details of the rural cost. The order will only proceed if you are happy with the shipping.
Delivery info: As these units ship on a pallet or skid they cannot be shipped/delivered to a private residence for health and safety reasons/rules & we will require a business address for delivery of this order that must have access to a forklift for unloading.
Designed for:
The removal, installation and transportation of single, tandem and duplex tyre and wheel combinations. Hydraulically activated lift arms handle wheel assemblies up to 400mm frame with tilt feature that aligns lift arms with spindle angle. Three ball bearing mounted castor wheels provide positive stability and easy manoeuvrability. Bearing mounted lift arms easily rotate vehicle rim for bolt pattern alignment.
Features:
Hydraulic system actuated to provide smooth, positive power for the removal and installation of single, tandem and duplex tyres and wheels
Heavy duty steel frame tilts to allow precise positioning of truck tyres.
Supports heavy 750kg commercial rims and tyres
Rolls easily on quality steel bearing castors
Includes heavy duty chain to keep load secure.
Specifications:
750kg Safe Working Capacity
Lift Arm Spread: 533mm (min) to 635mm (max)
Lifting Range: 60 - 275mm
Tilt Range: -2.5 to 10 degrees
Dimensions: 787(L) x 1092(W) x 895(H)mm
Click & Collect If you are in WA or Vic you can collect from our metro warehouses there by using the coupon code WAREHOUSECOLLECT when placing your order online. This will remove the shipping from the order & alert the staff in WA or Vic that you will be collecting personally. Once the order is ready we will email you the collection address & other details. NOTE: Do not put the coupon in the order comments section. Look for the coupon code link in your online shopping cart or the secured checkout.
