5T Single Acting Ram – 127mm Stroke
Product Code: ES-55
A 5-tonne single acting hydraulic ram with a 127mm stroke, featuring spring-loaded return and a high-strength alloy steel body built for heavy-duty industrial use.
Heavy-duty build for the harshest industrial sites
Fast spring-loaded retraction
Hardened chrome-plated piston
Flexible mounting — collar, piston & base threads
Description
The Eagle Pro ES series redefines durability for the harshest of industrial environments with its high-strength alloy steel construction. A hardened and chromed piston ensures superior service life by reducing wear and corrosion.
The ES series isn't only durable — it gets the job done. Heavy-duty, straight-pull return springs provide fast retraction, and for greater flexibility and easy mounting it comes with a collar, multiple piston threads, and base mounting holes.
The female coupler is supplied with a dust cover, preventing dirt and debris from entering the hydraulic system.
The Eagle Pro ES series complies with ASME B30.1 standards.
Features
Hardened alloy-steel guide ring prevents over-travel and reduces wear from off-centre loads
Heavy-duty wiper ring keeps out dust and debris, extending service life
High-strength composite bearings support off-centre loads without scoring the cylinder walls
Precision-machined high-strength alloy-steel body with a baked-enamel finish for durability and corrosion protection
Hardened, chromed piston resists wear and corrosion
Industrial U-cup seal prevents costly leaks
Heavy-duty straight-pull return springs for fast retraction
Includes a standard coupler with dust cover
Specifications
Cylinder Capacity @ 10,000 PSI 5t
Stroke 127mm
Effective Area 7.1 cm²
Oil Capacity 90.2 cm³
Collapsed Height (A) 215mm
Extended Height (B) 342mm
Collar Thread (C) 1-1/2 - 16
Collar Thread Length (X) 28mm
Outside Diameter (D) 25mm
Piston Diameter (F) 25mm
Piston Internal Thread (O) 3/4 - 16UNF
Piston Internal Length (P) 16mm
Base Bolt Circle (U) 25mm
Base Mounting Thread (V) 1/4 - 20UNC
Base Thread Depth (Z) 14mm
Weight 1.7kg
Warranty 12 months (trade use)
Intended Use
For industrial & fast paced heavy-duty applications where the convenience of hydraulic power can be utilised for spreading, clamping, pushing and lifting in power, gas & steel plants, refinery shutdown and civil construction, ship building, agricultural and transport equipment & mining applications.
